In this file you'll find 54 2D/3D symbols regarding retail, restaurant and supermarkets: refrigerated showcases such as dairy display, wall mounted and chest refrigerators, restaurant (fishes / meat) showstoppers, ice-cram freezers etc..
Look / download the PDF of contents
| Art. | Symbol name | Description | Size in. | Image |
|---|---|---|---|---|
| PM-850 | AAN - vertical refrigerated showcase 100 cm | AAN - vertical refrigerated showcase 100 cm | 39,4 x 33,4 x 77,2 |  |
| PM-851 | AAN - vertical refrigerated showcase 150 cm | AAN - vertical refrigerated showcase 150 cm | 59,1 x 33,4 x 77,2 |  |
| PM-852 | AAN - vertical refrigerated showcase 200 cm | AAN - vertical refrigerated showcase 200 cm | 78,7 x 33,4 x 77,2 |  |
| PM-853 | AAN - vertical refrigerated showcase (mirrored) 100 cm | AAN - vertical refrigerated showcase (mirrored) 100 cm | 39,4 x 33,4 x 77,2 |  |
| PM-854 | AAN - vertical refrigerated showcase (mirrored) 150 cm | AAN - vertical refrigerated showcase (mirrored) 150 cm | 59,1 x 33,4 x 77,2 |  |
| PM-855 | AAN - vertical refrigerated showcase (mirrored) 200 cm | AAN - vertical refrigerated showcase (mirrored) 200 cm | 78,7 x 33,4 x 77,2 |  |
| PM-856 | AAN - wall mounted refrigerated cabinet 100cm | AAN - wall mounted refrigerated cabinet 100cm | 39 x 25,8 x 29,5 |  |
| PM-857 | AAN - wall mounted refrigerated cabinet 150cm | AAN - wall mounted refrigerated cabinet 150cm | 58,7 x 25,8 x 29,5 |  |
| PM-858 | AAN - wall mounted refrigerated cabinet 200cm | AAN - wall mounted refrigerated cabinet 200cm | 78,3 x 25,8 x 29,5 |  |
| PM-859 | AAN - wall mounted refrigerated showcase 100 cm | AAN - wall mounted refrigerated showcase 100 cm | 39,2 x 23,6 x 53,1 |  |
| PM-860 | AAN - wall mounted refrigerated showcase 150 cm | AAN - wall mounted refrigerated showcase 150 cm | 58,9 x 23,6 x 53,1 |  |
| PM-861 | AAN - wall mounted refrigerated showcase 200 cm | AAN - wall mounted refrigerated showcase 200 cm | 78,5 x 23,6 x 53,1 |  |
| PM-862 | Drinks vertical showcase 59,5x62x200H | Drinks vertical showcase 59,5x62x200H | 23,4 x 25,2 x 78,7 |  |
| PM-863 | Drinks vertical showcase 60x74x206H | Drinks vertical showcase 60x74x206H | 23,6 x 30 x 81,1 |  |
| PM-864 | Fish showcase 148 | Fish showcase 148 | 58,3 x 25,9 x 63 |  |
| PM-865 | Ice cream freezer 70x140H100 | Ice cream freezer 70x140H100 | 27,6 x 55,1 x 39,4 |  |
| PM-866 | Ice cream freezer 75x147H100 | Ice cream freezer 75x147H100 | 29,5 x 57,9 x 39,4 |  |
| PM-867 | Ice cream freezer 80x150H100 | Ice cream freezer 80x150H100 | 31,5 x 59,1 x 39,4 |  |
| PM-868 | Ice cream freezer sammontana 80x65 | Ice cream freezer sammontana 80x65 | 31,5 x 25,6 x 35,4 |  |
| PM-869 | RWC - L STD 100 | RWC - L STD 100 | 39,4 x 27,6 x 61,4 |  |
| PM-870 | RWC - L STD 125 | RWC - L STD 125 | 49,2 x 27,6 x 61,4 |  |
| PM-871 | RWC - L STD 150 | RWC - L STD 150 | 59,1 x 27,6 x 61,4 |  |
| PM-872 | RWC - L STD 175 | RWC - L STD 175 | 68,9 x 27,6 x 61,4 |  |
| PM-873 | RWC - L STD 200 | RWC - L STD 200 | 78,7 x 27,6 x 61,4 |  |
| PM-874 | RWC - M ST 100 | RWC - M ST 100 | 39,4 x 19,7 x 20,9 |  |
| PM-875 | RWC - M ST 150 | RWC - M ST 150 | 59,1 x 19,7 x 20,9 |  |
| PM-876 | RWC - T 100 | RWC - T 100 | 39,4 x 23,6 x 31,5 |  |
| PM-877 | RWC - T 150 | RWC - T 150 | 59,1 x 23,6 x 31,5 |  |
| PM-878 | RWC - T 200 | RWC - T 200 | 78,7 x 23,6 x 31,5 |  |
| PM-879 | RWC - T 300 | RWC - T 300 | 118,1 x 19,7 x 31,5 |  |
| PM-880 | SF - chest refigerator BT15 | SF - chest refigerator BT15 | 41,3 x 61 x 35,4 |  |
| PM-881 | SF - chest refigerator BT20 | SF - chest refigerator BT20 | 41,3 x 80,7 x 35,4 |  |
| PM-882 | SF - chest refigerator BT25 | SF - chest refigerator BT25 | 41,3 x 100,4 x 35,4 |  |
| PM-883 | SF dairy display case L98 | SF dairy display case L98 | 38,6 x 32,8 x 75,8 |  |
| PM-884 | SF dairy display case L130 | SF dairy display case L130 | 51,2 x 32,8 x 75,8 |  |
| PM-885 | SF dairy display case L160 | SF dairy display case L160 | 63 x 32,8 x 75,8 |  |
| PM-886 | SF dairy display case L186 | SF dairy display case L186 | 73,2 x 32,8 x 75,8 |  |
| PM-887 | SF dairy display case L250 | SF dairy display case L250 | 98,4 x 32,8 x 75,8 |  |
| PM-888 | SF P80 L100 | SF P80 L100 | 39,4 x 33,5 x 75 |  |
| PM-889 | SF P80 L135 | SF P80 L135 | 53,1 x 33,5 x 75 |  |
| PM-890 | SF P80 L180 | SF P80 L180 | 70,9 x 33,5 x 75 |  |
| PM-891 | SF P80 L250 | SF P80 L250 | 98,4 x 33,5 x 75 |  |
| PM-892 | SF vertical refrigerated showcase P60x094 | SF vertical refrigerated showcase P60x094 | 37 x 24,4 x 78,7 |  |
| PM-893 | SF vertical refrigerated showcase P60x126 | SF vertical refrigerated showcase P60x126 | 49,6 x 24,4 x 78,7 |  |
| PM-894 | SF vertical refrigerated showcase P60x182 | SF vertical refrigerated showcase P60x182 | 71,7 x 24,4 x 78,7 |  |
| PM-895 | TF-B-500 | TF-B-500 | 33,3 x 32,3 x 71,5 |  |
| PM-896 | TF-FISH 4 | TF-FISH 4 | 55,8 x 29,7 x 50,6 |  |
| PM-897 | TF-FISH 6 | TF-FISH 6 | 81 x 29,7 x 50,6 |  |
| PM-898 | TF-SN-350 | TF-SN-350 | 25,8 x 23,9 x 71,3 |  |
| PM-899 | TF-SN-700 | TF-SN-700 | 25,8 x 45,4 x 71,3 |  |
| PM-900 | TF-SO-350 | TF-SO-350 | 25,9 x 24,2 x 72,8 |  |
| PM-901 | TF-SO-500 | TF-SO-500 | 30,3 x 28,1 x 71,9 |  |
| PM-902 | TF-SO-700 | TF-SO-700 | 25,8 x 45,4 x 72,8 |  |
| PM-903 | TF-SO-1000 | TF-SO-1000 | 29,1 x 53,3 x 72 |  |
Follow Paolo Marcuccetti's Gumroad® shop page
where you can buy this and other packages related to my Vectorworks® production.
After the payment is confirmed, download should start immediately.
What you'll get is a Vectorworks® file that can be opened with Vectorworks® 2020 or newer.
Simply open this file and grab / copy the symbol / group you need to use in your drawing. That's all!
